- Light-curing 3D printing WEBSITE POSITION ：Home -- Products -- Light-curing 3D printing
-
- Product Name：DLP6500UV [No:005]
- Type : Light-curing 3D printing
- DMD : DLP6500
- Resolution : 1920*1080
Detail 1.SpecDisplay technique
TI DLP 0.65-inch 1080P DMD
Resolution
1920*1080
Light source
LED UV405nm
Light channel
Single channel
Optical power
2.5W@55W
Offset
Without offset
Contrast
1500:1
Uniformity
>90%
Offset
100%
Power supply
AC110V~240V，50/60HZ, DC12v5A
Total power
<60W
Dimension
L190*W173*H83mm
Material
Body: All metal; Optics：All glass；
interface
DCIN
HDMI-TYPEA
miniUSB
Exit LEDONOFF,PWR ONOFF
2. Model
NO. Production name Printing Resolution Image@WD Optical distortion wavelength Focus 1 PDC05-S 50-75um 96*54@100T120 0.60% 405/385 zoom 144*81@170T200 2 PDC05-B 100-150um 192*108@230T260 0.80% 405/385 zoom 288*162@350T420 3 PDC05-50 46-60um 96*54@135 0.10% 405/385 Fix 4 PDC05-60 53-67um 115.2*64.8@158 0.10% 405/385 Fix 5 PDC05-70 66-75um 134*75.6@192 0.10% 405/385 Fix 6 PDC05-80 73-86um 153.6*86.4@228 0.10% 405/385 Fix 7 PDC05-100 90-120um 192*108@295 0.05% 405/385 Fix 8 PDC05-150 130-180um 288*162@470 0.05% 405/385 Fix 3.Size
* More information reference PDC05 user’ Guide
